RFC7239:Forwarded HTTP Extension

A. Petersson ,

M. Nilsson




Proposed Standard




Internet Engineering Task Force (IETF) A. Petersson Request for Comments: 7239 M. Nilsson Category: Standards Track Opera Software ISSN: 2070-1721 June 2014 Forwarded HTTP Extension Abstract This document defines an HTTP extension header field that allows proxy components to disclose information lost in the proxying process, for example, the originating IP address of a request or IP address of the proxy on the user-agent-facing interface. In a path of proxying components, this makes it possible to arrange it so that each subsequent component will have access to, for example, all IP addresses used in the chain of proxied HTTP requests. This document also specifies guidelines for a proxy administrator to anonymize the origin of a request. Status of This Memo This is an Internet Standards Track document. This document is a product of the Internet Engineering Task Force (IETF). It represents the consensus of the IETF community. It has received public review and has been approved for publication by the Internet Engineering Steering Group (IESG). Further information on Internet Standards is available in Section 2 of RFC 5741 . Information about the current status of this document, any errata, and how to provide feedback on it may be obtained at http://www.rfc-editor.org/info/rfc7239 . Petersson & Nilsson Standards Track [Page 1]
------
RFC 7239 Forwarded HTTP Extension June 2014 Copyright Notice Copyright (c) 2014 IETF Trust and the persons identified as the document authors. All rights reserved. This document is subject to BCP 78 and the IETF Trust's Legal Provisions Relating to IETF Documents ( http://trustee.ietf.org/license-info ) in effect on the date of publication of this document. Please review these documents carefully, as they describe your rights and restrictions with respect to this document. Code Components extracted from this document must include Simplified BSD License text as described in Section 4.e of the Trust Legal Provisions and are provided without warranty as described in the Simplified BSD License. Table of Contents 1 . Introduction .................................................... 3 2 . Notational Conventions .......................................... 4 3 . Syntax Notations ................................................ 4 4 . Forwarded HTTP Header Field ..................................... 4 5 . Parameters ...................................................... 6 5.1 . Forwarded By ............................................... 6 5.2 . Forwarded For .............................................. 6 5.3 . Forwarded Host ............................................. 7 5.4 . Forwarded Proto ............................................ 7 5.5 . Extensions ................................................. 7 6 . Node Identifiers ................................................ 8 6.1 . IPv4 and IPv6 Identifiers .................................. 9 6.2 . The "unknown" Identifier ................................... 9 6.3 . Obfuscated Identifier ...................................... 9 7 . Implementation Considerations .................................. 10 7.1 . HTTP Lists ................................................ 10 7.2 . Header Field Preservation ................................. 10 7.3 . Relation to Via ........................................... 10 7.4 . Transition ................................................ 11 7.5 . Example Usage ............................................. 11 8 . Security Considerations ........................................ 12 8.1 . Header Validity and Integrity ............................. 12 8.2 . Information Leak .......................................... 12 8.3 . Privacy Considerations .................................... 12 9 . IANA Considerations ............................................ 14 10 . References .................................................... 14 10.1 . Normative References ..................................... 14 10.2 . Informative References ................................... 15 Appendix A . Acknowledgments ....................................... 16 Petersson & Nilsson Standards Track [Page 2]
------
RFC 7239 Forwarded HTTP Extension June 2014 1 . Introduction In today's HTTP landscape, there are a multitude of different applications that act as proxies for the user agents. In many cases, these proxies exists without the action or knowledge of the end-user. These cases occur, for example, when the proxy exists as a part of the infrastructure within the organization running the web server. Such proxies may be used for features such as load balancing or crypto offload. Another example is when the proxy is used within the same organization as the user, and the proxy is used to cache resources. However, these proxies make the requests appear as if they originated from the proxy's IP address, and they may change other information in the original request. This represents a loss of information from the original request. This loss of information can cause problems for a web server that has a specific use for the clients' IP addresses that will not be met by using the address of the proxy or other information changed by the proxy. The main uses of this information are for diagnostics, access control, and abuse management. Diagnostic functions can include event logging, troubleshooting, and statistics gathering, and the information collected is usually only stored for short periods of time and only gathered in response to a particular problem or a complaint from the client. Access control can be operated by configuring a list of client IP addresses from which access is permitted, but this approach will not work if a proxy is used, unless the proxy is trusted and is, itself, configured with a list of allowed client addresses for the server. Cases of abuse require identification of the abuser and this uses many of the same features identified for diagnostics. Most of the time that a proxy is used, this loss of information is not the primary purpose, or even a desired effect, of using the proxy. Thus, to restore the desired functionality when a proxy is in use, a way of disclosing the original information at the HTTP level is needed. Clearly, however, when the purpose of using a proxy is to provide client anonymity, the proxy will not use the feature defined in this document. It should be noted that the use of a reverse proxy also hides information. Again, where the loss of information is not a deliberate function of the use of the reverse proxy, it can be desirable to find a way to encode the information within the HTTP messages so that the consumer can see it. A common way to disclose this information is by using the non- standard header fields such as X-Forwarded-For, X-Forwarded-By, and X-Forwarded-Proto. There are many benefits to using a standardized Petersson & Nilsson Standards Track [Page 3]
------
RFC 7239 Forwarded HTTP Extension June 2014 approach to commonly desired protocol function: not least is interoperability between implementations. This document standardizes a header field called "Forwarded" and provides the syntax and semantics for disclosing such information. "Forwarded" also combines all the information within one single header field, making it possible to correlate that information. With the header field format described in this document, it is possible to know what information belongs together, as long as the proxies are trusted. Such conclusions are not possible to make with the X-Forwarded class of header fields. The header field defined in this document is optional such that implementations of proxies that are intended to provide privacy are not required to operate or implement the header field. Note that similar issues to those described for proxies also arise with use of NATs. This is discussed further in [ RFC6269 ]. 2 . Notational Conventions The key words "MUST", "MUST NOT", "REQUIRED", "SHALL", "SHALL NOT", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in [ RFC2119 ]. 3 . Syntax Notations This specification uses the Augmented Backus-Naur Form (ABNF) notation of [ RFC5234 ] with the list rule extension defined in Section 7 of [RFC7230] . 4 . Forwarded HTTP Header Field The "Forwarded" HTTP header field is an OPTIONAL header field that, when used, contains a list of parameter-identifier pairs that disclose information that is altered or lost when a proxy is involved in the path of the request. Due to the sensitive nature of the data passed in this header field (see Sections 8.2 and 8.3 ), this header field should be turned off by default. Further, each parameter should be configured individually. "Forwarded" is only for use in HTTP requests and is not to be used in HTTP responses. This applies to forwarding proxies, as well as reverse proxies. Information passed in this header field can be, for example, the source IP address of the request, the IP address of the incoming interface on the proxy, or whether HTTP or HTTPS was used. If the request is passing through several proxies, each proxy can add a set of parameters; it can also remove previously added "Forwarded" header fields. Petersson & Nilsson Standards Track [Page 4]
------
RFC 7239 Forwarded HTTP Extension June 2014 The top-level list is represented as a list of HTTP header field-values as defined in Section 3.2 of [RFC7230] . The first element in this list holds information added by the first proxy that implements and uses this header field, and each subsequent element holds information added by each subsequent proxy. Because this header field is optional, any proxy in the chain may choose not to update this header field. Each field-value is a semicolon-separated list; this sublist consists of parameter-identifier pairs. Parameter-identifier pairs are grouped together by an equals sign. Each parameter MUST NOT occur more than once per field-value. The parameter names are case-insensitive. The header field value can be defined in ABNF syntax as: Forwarded = 1#forwarded-element forwarded-element = [ forwarded-pair ] *( ";" [ forwarded-pair ] ) forwarded-pair = token "=" value value = token / quoted-string token = <Defined in [RFC7230], Section 3.2.6 > quoted-string = <Defined in [RFC7230], Section 3.2.6 > Examples: Forwarded: for="_gazonk" Forwarded: For="[2001:db8:cafe::17]:4711" Forwarded: for=192.0.2.60;proto=http;by=203.0.113.43 Forwarded: for=192.0.2.43, for=198.51.100.17 Note that as ":" and "[]" are not valid characters in "token", IPv6 addresses are written as "quoted-string". A proxy server that wants to add a new "Forwarded" header field value can either append it to the last existing "Forwarded" header field after a comma separator or add a new field at the end of the header block. A proxy MAY remove all "Forwarded" header fields from a request. It MUST, however, ensure that the correct header field is updated in case of multiple "Forwarded" header fields. Petersson & Nilsson Standards Track [Page 5]
------
RFC 7239 Forwarded HTTP Extension June 2014 5 . Parameters This document specifies a number of parameters and valid values for each of them: o "by" identifies the user-agent facing interface of the proxy. o "for" identifies the node making the request to the proxy. o "host" is the host request header field as received by the proxy. o "proto" indicates what protocol was used to make the request. 5.1 . Forwarded By The "by" parameter is used to disclose the interface where the request came in to the proxy server. When proxies choose to use the "by" parameter, its default configuration SHOULD contain an obfuscated identifier as described in Section 6.3 . If the server receiving proxied requests requires some address-based functionality, this parameter MAY instead contain an IP address (and, potentially, a port number). A third option is the "unknown" identifier described in Section 6.2 . The syntax of a "by" value, after potential quoted-string unescaping, conforms to the "node" ABNF described in Section 6 . This is primarily added by reverse proxies that wish to forward this information to the backend server. It can also be interesting in a multihomed environment to signal to backend servers from which the request came. 5.2 . Forwarded For The "for" parameter is used to disclose information about the client that initiated the request and subsequent proxies in a chain of proxies. When proxies choose to use the "for" parameter, its default configuration SHOULD contain an obfuscated identifier as described in Section 6.3 . If the server receiving proxied requests requires some address-based functionality, this parameter MAY instead contain an IP address (and, potentially, a port number). A third option is the "unknown" identifier described in Section 6.2 . The syntax of a "for" value, after potential quoted-string unescaping, conforms to the "node" ABNF described in Section 6 . Petersson & Nilsson Standards Track [Page 6]
------
RFC 7239 Forwarded HTTP Extension June 2014 In a chain of proxy servers where this is fully utilized, the first "for" parameter will disclose the client where the request was first made, followed by any subsequent proxy identifiers. The last proxy in the chain is not part of the list of "for" parameters. The last proxy's IP address, and optionally a port number, are, however, readily available as the remote IP address at the transport layer. It can, however, be more relevant to read information about the last proxy from preceding "Forwarded" header field's "by" parameter, if present. 5.3 . Forwarded Host The "host" parameter is used to forward the original value of the "Host" header field. This can be used, for example, by the origin server if a reverse proxy is rewriting the "Host" header field to some internal host name. The syntax for a "host" value, after potential quoted-string unescaping, MUST conform to the Host ABNF described in Section 5.4 of [RFC7230] . 5.4 . Forwarded Proto The "proto" parameter has the value of the used protocol type. The syntax of a "proto" value, after potential quoted-string unescaping, MUST conform to the URI scheme name as defined in Section 3.1 in [RFC3986] and registered with IANA according to [ RFC4395 ]. Typical values are "http" or "https". For example, in an environment where a reverse proxy is also used as a crypto offloader, this allows the origin server to rewrite URLs in a document to match the type of connection as the user agent requested, even though all connections to the origin server are unencrypted HTTP. 5.5 . Extensions Extensions allow for additional parameters and values. Extensions can be particularly useful in reverse proxy environments. All extension parameters SHOULD be registered in the "HTTP Forwarded Parameter" registry. If certain extensions are expected to have widespread deployment, they SHOULD also be standardized. This is further discussed in Section 9 . Petersson & Nilsson Standards Track [Page 7]
------
RFC 7239 Forwarded HTTP Extension June 2014 6 . Node Identifiers The node identifier is one of the following: o The client's IP address, with an optional port number o A token indicating that the IP address of the client is not known to the proxy server o A generated token, allowing for tracing and debugging, while allowing the internal structure or sensitive information to be hidden The node identifier is defined by the ABNF syntax as: node = nodename [ ":" node-port ] nodename = IPv4address / "[" IPv6address "]" / "unknown" / obfnode IPv4address = <Defined in [RFC3986], Section 3.2.2 > IPv6address = <Defined in [RFC3986], Section 3.2.2 > obfnode = "_" 1*( ALPHA / DIGIT / "." / "_" / "-") node-port = port / obfport port = 1*5DIGIT obfport = "_" 1*(ALPHA / DIGIT / "." / "_" / "-") DIGIT = <Defined in [RFC5234], Section 3.4 > ALPHA = <Defined in [ RFC5234 ], Section B.1> Each of the identifiers may optionally have the port identifier, for example, allowing the identification of the endpoint in a NATed environment. The "node-port" can be identified either by its port number or by a generated token obfuscating the real port number. An obfuscated port may be used in situations where the possessor of the proxy wants the ability to trace requests -- for example, in debug purposes -- but does not want to reveal internal information. Note that the ABNF above also allows port numbers to be appended to the "unknown" identifier. Interpretation of such notation is, however, left to the possessor of a proxy adding such a value to the header field. To distinguish an "obfport" from a port, the "obfport" MUST have a leading underscore. Further, it MUST also consist of only "ALPHA", "DIGIT", and the characters ".", "_", and "-". It is important to note that an IPv6 address and any nodename with node-port specified MUST be quoted, since ":" is not an allowed character in "token". Petersson & Nilsson Standards Track [Page 8]
------
RFC 7239 Forwarded HTTP Extension June 2014 Examples: "192.0.2.43:47011" "[2001:db8:cafe::17]:47011" 6.1 . IPv4 and IPv6 Identifiers The ABNF rules for "IPv6address" and "IPv4address" are defined in [ RFC3986 ]. The "IPv6address" SHOULD comply with textual representation recommendations [ RFC5952 ] (for example, lowercase, compression of zeros). Note that the IP address may be one from the internal nets, as defined in [ RFC1918 ] and [ RFC4193 ]. Also, note that an IPv6 address is always enclosed in square brackets. 6.2 . The "unknown" Identifier The "unknown" identifier is used when the identity of the preceding entity is not known, but the proxy server still wants to signal that a forwarding of the request was made. One example would be a proxy server process generating an outgoing request without direct access to the incoming request TCP socket. 6.3 . Obfuscated Identifier A generated identifier may be used where there is a wish to keep the internal IP addresses secret, while still allowing the "Forwarded" header field to be used for tracing and debugging. This can also be useful if the proxy uses some sort of interface labels and there is a desire to pass them rather than an IP address. Unless static assignment of identifiers is necessary for the server's use of the identifiers, obfuscated identifiers SHOULD be randomly generated for each request. If the server requires that identifiers persist across requests, they SHOULD NOT persist longer than client IP addresses. To distinguish the obfuscated identifier from other identifiers, it MUST have a leading underscore "_". Furthermore, it MUST also consist of only "ALPHA", "DIGIT", and the characters ".", "_", and "-". Example: Forwarded: for=_hidden, for=_SEVKISEK Petersson & Nilsson Standards Track [Page 9]
------
RFC 7239 Forwarded HTTP Extension June 2014 7 . Implementation Considerations 7.1 . HTTP Lists Note that an HTTP list allows white spaces to occur between the identifiers, and the list may be split over multiple header fields. As an example, the header field Forwarded: for=192.0.2.43,for="[2001:db8:cafe::17]",for=unknown is equivalent to the header field Forwarded: for=192.0.2.43, for="[2001:db8:cafe::17]", for=unknown which is equivalent to the header fields Forwarded: for=192.0.2.43 Forwarded: for="[2001:db8:cafe::17]", for=unknown 7.2 . Header Field Preservation There are some cases when this header field should be kept and some cases where it should not be kept. A directly forwarded request should preserve and possibly extend it. If a single incoming request causes the proxy to make multiple outbound requests, special care must be taken to decide whether or not the header field should be preserved. In many cases, the header field should be preserved, but if the outbound request is not a direct consequence of the incoming request, the header field should not be preserved. Consider also the case when a proxy has detected a content mismatch in a 304 response and is following the instructions in [RFC7232], Section 4.1 to repeat the request unconditionally, in which case the new request is still basically a direct consequence of the origin request, and the header field should probably be kept. 7.3 . Relation to Via The "Via" header field (see [RFC7230], Section 5.7.1 ) is a header field with a similar use case as this header field. The "Via" header field, however, only provides information about the proxy itself, and thereby leaves out the information about the client connecting to the proxy server. The "Forwarded" header field, on the other hand, has relaying information from the client-facing side of the proxy server as its main purpose. As "Via" is already widely deployed, its format cannot be changed to address the problems that "Forwarded" addresses. Petersson & Nilsson Standards Track [Page 10]
------
…
